The Nanbo C210 self-dumping road sweeper features industry-first functionality and holds a national invention patent. It utilizes four pneumatic tires, making it suitable for various surface types. Equipped with a rear dual-wheel hub drive system, it offers powerful climbing capability and a maximum travel speed of 25 km/h, significantly enhancing operational efficiency. The main brush system features an integrated lifting mechanism and holds a national invention patent.
Suitable locations: Municipal roads, factories, schools and universities, parks, public squares, villa complexes, and lanes for motor and non-motor vehicles.
Suitable surfaces: Concrete, asphalt, marble, etc.
The Nanbo C210 self-dumping road sweeper features industry-first functionality and holds a national invention patent. It utilizes four pneumatic tires, making it suitable for various surface types. Equipped with a rear dual-wheel hub drive system, it offers powerful climbing capability and a maximum travel speed of 25 km/h, significantly enhancing operational efficiency. The main brush system features an integrated lifting mechanism and holds a national invention patent.
Suitable locations: Municipal roads, factories, schools and universities, parks, public squares, villa complexes, and lanes for motor and non-motor vehicles.
Suitable surfaces: Concrete, asphalt, marble, etc.
Key Features of the C210 Self-dumping Road Sweeper
Patented Integrated-Lift Sweeping System
The patented sweeping system allows the main brush assembly to lift as a complete unit, providing up to 120 mm of ground clearance for crossing speed bumps and other road obstacles.
Electric Power Steering and Reversing Camera
Electric power-assisted steering reduces operator effort and improves handling comfort. The reversing camera provides additional visibility when backing up or manoeuvring in confined areas.
Dual-Fan Vacuum System
Two high-power suction fans work with a dual-cartridge filtration system to improve dust and debris collection during demanding road-sweeping operations.
450 L Water Tank and Multi-Nozzle Spraying
The large 450 L water tank supplies multiple front and rear spray nozzles, supporting extended dust-suppression operation while reducing refill frequency.
Automatic Hydraulic Hopper Dumping
The high-capacity waste hopper uses a hydraulic lifting system for automatic dumping, reducing manual handling and improving unloading efficiency.
Integrated Welded Chassis
The one-piece welded chassis provides a strong structural foundation and supports stable operation under demanding working conditions.
Multiple Cleaning Modes
Different operating modes can be selected to collect various types of debris and control airborne dust across roads, industrial parks and municipal areas.
High-Pressure Auxiliary Cleaning System
An automatic high-pressure hose reel, handheld spray gun and rear high-pressure spray bar provide flexible cleaning for corners, roadside facilities and stubborn surface dirt.
Parameter
Specification
Value
Maximum sweeping productivity
17,000 m²/h
Maximum travel speed
25 km/h
Maximum working speed
10 km/h
Maximum sweeping width
2,100 mm
Water tank capacity
450 L
Waste hopper capacity
200 L
Number of front side brushes
2
Number of rear side brushes
2
Operating time
6–7 hours
Main and side brush lift
Automatic
Hopper dumping system
Fully automatic hydraulic dumping
Power supply
48 V
Machine weight
1,200 kg
Dimensions (L × W × H)
3,200 × 1,800 × 2,000 mm
Technologies
Integrated Cleaning Systems
Practical cleaning technologies, reliable power systems and user-friendly controls configured for professional cleaning applications.
Modular Function Design
Sweeping, scrubbing, water recovery, dust suppression, high-pressure washing and waste collection — each tuned to the environment and surface.
Stability & Safety
Engineered for cleaning efficiency, operational stability, operator safety and convenient maintenance with accessible service components.
Pre-delivery Testing
Every machine undergoes functional inspection covering cleaning system, water supply, suction, electrics, driving and safety devices.
Custom & OEM/ODM
Optional configurations available for distributors and contractors — tailored to area, surface, waste type, working time and local requirements.
Anhui Nanbo Intelligent Environmental Equipment Co., Ltd. — founded in 2015, headquartered in Wuhu. We are a national High-Tech Enterprise with 80+ patents and ISO 9001 certification, focused on the R&D and manufacturing of floor scrubbers, floor sweepers, high-pressure washers and new-energy sanitation vehicles.
Three main factors to consider: cleaning area, floor material and dominant soil type. Hand-push scrubbers are typically used for areas under 3,000 m², while ride-on versions suit 5,000 m² and above. Sweepers handle dry dust and debris; scrubbers handle oil and water spills — many facilities run both for the best result.
Sweepers use dry technology (sweep + suction) to remove dust, chips and loose debris without water. Scrubbers use wet technology (spray + scrub + suction) with water and detergent to remove oil and liquid spills, leaving the floor dry immediately. They serve different purposes and are not substitutes.
Pricing varies significantly depending on model, configuration, battery type and quantity. As a source manufacturer, we offer competitive factory-direct pricing and can tailor packages to your project. Please contact us for a precise quotation based on your specific needs.
Lead-acid is the economical choice for single-shift (8-hour) operations. Lithium is recommended for double or triple shifts: it charges in 2–3 hours, lasts roughly 2,000 charge cycles and requires no maintenance over its lifetime.
